UnoXT2 ZX Spectrum Next Compatible Clone

Second Generation of UnoXT Development Board with possibility running 20 Cores of Retro-Computers including legendary ZX Spectrum Next.
Spartan 6 SLX25, BGA256 chip, 25K cells, SRAM 4MB, SDRAM 64MB, VGA, Audio Out with Volume control, SPDIF, PS/2 Keyboard and Mouse, SD-CARD or uSD-CARD, DB9 Joystick, ESP-07 Wi-Fi Module.

Have 20 Cores of Retro-Computers

ZX Spectrum EXP27
ZX Next
TSConf
Atari 800XL
MSX1
Sega Master System
Radio-86RK
NES
C64
Acorn Atom
Pravetz-8D
Amstrad CPC6128
MSX2
Next186Lite
SAM Coupe
Apple2
ColecoVision
Orion-2010
Atari 2600
BK-0010
As usual – Favorite Core – ZX Spectrum Next!!!

Assembly

Schematics UnoZX2

Gerbers UnoZX2

BOM

Acrilic Enclosure

Firmware flash.xt2

Based on UnoXT Rev.F Board – https://gitlab.com/emax73g/unoxt-hardware/-/tree/main/
